Pseudonymization

We've Updated Our Privacy Policy

IANAL

I am not a lawyer.

General Data Protection Regulation (GDPR)

A new set of EU-based policies about how companies can collect and use consumer data. GDPR passed in 2016, but that included a waiting period for companies to adjust.

May 25, 2018

The Rules

Lawfulness, Fairness and Transparency

Purpose Limitation

Data Minimization

Accuracy

Storage Limitation

Integrity and Transparency

Personal Data

GDPR sets a broad definition of what constitutes personal data.

Any information that is owned by an individual, or that could identify a user, is now off-limits for most purposes without proper consent.

Personal Data (examples)

• Full Names
• Home Addresses
• Email Addresses
• Telephone Numbers
• DOB and/or Birthplace
• any Identification Numbers
  (e.g. Driver's License, Passport, etc.)

Data Privacy Techniques

🎉 no more legal stuff 🎉

Two Popular Methods

PSEUDONYMIZATION

ANONYMIZATION

PSEUDONYMIZATION

An approach for treating personal data so that it cannot be used to identify individual users without the use of additional information. Most techniques involve replacing data with a placeholder value, or pseudonym. This pseudonym may be a masked version of a record or a token used for retrieving the original value.

Recommended by GDPR

ANONYMIZATION

A permanent de-identification of a data set so that no party will be able to identify the individuals in reference no matter what additional data they possess. Since anonymized data cannot be used to identify any individual, it is no longer considered personal data and as such does not fall under the purview of GDPR.

Pseudonymization Techniques

Data Masking

altering or replacing a record or part of a record without changing its format. For example, an unmasked social security number (SSN) might be stored as
679-69-8549,
but a masked SSN using a technique to substitute the digits might look like
145-126-7741.

Approximation

a technique for replacing specific personal data with less specific values. For example, if a user's date of birth is August 20, 1997, then an approximated record might be stored as July 1- September 25, 1997, or even just 1997..

Encryption

a cryptographic process that converts data into an unreadable format (ciphertext) so that only individuals or systems with access to the appropriate key can decrypt and read it.

No. Not mandatory according to GDPR

Tokenization

tokenizing a piece of data is to replace it with a unique token that acts as a stand-in which can be used to retrieve the original value.

Simple Implementation Example

Python already supports a common pattern that allows an engineer to replace a attribute with a set of methods that can intercept values as they're written and read.

either getter/setter or properties

For the following examples we'll use an overly simplified data masking and unmasking algorithm

def shift(string, reverse=False):
    """Shift ord value of character within range."""

    new_string = []

    for char in string:
        try:
            value = ord(char)

            if value in range(ord('A'), ord('Z') + 1):
                min = ord('A')
                max = ord('Z')
            elif value in range(ord('a'), ord('z') + 1):
                min = ord('a')
                max = ord('z')

            values = range(min, max + 1)

            if reverse:
                index = values.index(value) - 1
            else:
                index = values.index(value) + 1

            new_string.append(chr(values[index % len(values)]))

        except:
            new_string.append(char)

    return ''.join(new_string)


then to mask and unmask...

def mask(value):
    return shift(value)


def unmask(value):
    return shift(value, True)


looks something like:

$ python simple.py Frank Valcarcel
MASKING "Frank Valcarcel"
MASKED "Gsbol Wbmdbsdfm"
UNMASKED "Frank Valcarcel"


Simple Implementation Example
getter/setter

class User:
    def __init__(self):
        self._name = None

    @property
    def name(self):
        return self._name

    @name.setter
    def name(self, value):
        self._name = value


looks something like:

$ python
>>> user = User()
>>> user.name = "Frank Valcarcel"
>>> print(f'user.name => {user.name}')
user.name => Frank Valcarcel
>>> print(f'user._name => {user._name}')
user._name => Gsbol Wbmdbsdfm


django Example

A Simple django User Model

from django.db import models
from django.contrib.auth.models import AbstractUser

class User(AbstractUser):
    name = models.CharField(max_length=128, blank=True)
    phone = models.CharField(max_length=17, blank=True)
    date_of_birth = models.DateField(blank=True, null=True)
    ip_address = models.GenericIPAddressField(blank=True, null=True)


which fields are personal data?

ALL OF THEM

utils.py

def shift(string, reverse=False):
    """Shift ord value of character within range."""
    new_string = []
    for char in string:
        try:
            value = ord(char)...
            new_string.append(chr(values[index % len(values)]))
        except:
            new_string.append(char)
    return ''.join(new_string)

def mask(value):
    return shift(value)

def unmask(value):
    return shift(value, True)


Updated user/models.py

from django.db import models
from django.contrib.auth.models import AbstractUser

from app.utils import mask, unmask

class User(AbstractUser):
    _name = models.CharField(max_length=128, blank=True)

    @property
    def name(self):
        return unmask(self._name)

    @name.setter
    def name(self, value):
        self._name = mask(value)


Checklist

☐ Update the QuerySet

☐ Exclude Pseudonyms

☐ Update django-admin

Update the QuerySet (1)

as defined, our model can not be queried using any of the unmasked values. e.g. we can not call methods like: User.objects.filter(name='Frank')

to get this working, we're going to overide our model's QuerySet, more specifically the _filter_or_exclude method

Update the QuerySet (2)

let's look at the source code... django.db.models.query

Update the QuerySet (3)

so let's just insert our masked values in, and super the parent instance of models.QuerySet for everything else

Update the QuerySet (4)

class UserQuerySet(models.QuerySet):
    def _filter_or_exclude(self, negate, *args, **kwargs):

        masked_fields = ['name']

        for field in masked_fields:
            value = kwargs.pop(field, None)
            if value is not None:
                kwargs['_{}'.format(field)] = mask(value)

        return super(UserQuerySet, self)._filter_or_exclude(negate, *args, **kwargs)


Update the QuerySet (5)

To finish this, we override the AuthUserManager.get_queryset

class UserManager(AuthUserManager):
    def get_queryset(self):
        return UserQuerySet(self.model)

class User(AbstractUser):
	...
	objects = UserManager()


✅ User.objects.filter(name='Frank')
✅ User.objects.exclude(name='Frank')

Checklist

☑️ Update the QuerySet

☐ Exclude Pseudonyms

☐ Update django-admin

Exclude Pseudonyms (1)

pseudonyms are useless and will pollute our models

django has this method defer we can call on QuerySets so let's look at the source code again... QuerySet.defer()

Exclude Pseudonyms (2)

This will be an easy addition now that we override models.QuerySet

class UserQuerySet(models.QuerySet):
    def _filter_or_exclude(self, negate, *args, **kwargs):

        masked_fields = ['name']
        unmasked_fields = [f'_{field}' for field in masked_fields]

        for field in masked_fields:
            value = kwargs.pop(field, None)
            if value is not None:
                kwargs[f'_{field}'] = mask(value)

        return super(UserQuerySet, self)._filter_or_exclude(negate, *args, **kwargs).defer(*unmasked_fields)


Exclude Pseudonyms (3)

>>> u = User.objects.filter(name='Frank Valcarcel')
>>> u.__dict__
{'id': 1, 'password': 'pbkdf2_sha256...=', 'last_login': datetime.datetime(2018, 6, 11, 16, 20, 19, 775436, tzinfo=), 'is_superuser': True, 'username': 'frank', 'first_name': 'Frank', 'last_name': '', 'email': 'katie@cuttlesoft.com', 'is_staff': True, 'is_active': True, 'date_joined': datetime.datetime(2018, 6, 11, 16, 20, 14, 334272, tzinfo=)}


Note: I did not override the all() query, but query methods that call filter like get will behave this way.

Checklist

☑️ Update the QuerySet

☑️ Exclude Pseudonyms

☐ Update django-admin

Update django-admin (1)

write/read is masked/unmasked... but what about the django-admin?

We need to update our admin so we can read and write appropriately

Update django-admin (2)

    class Meta:
        model = User

        fields = ('username', 'password', 'name')


Update django-admin (3)

class UserChangeForm(AuthUserChangeForm):
    name = forms.CharField()

    def __init__(self, *args, **kwargs):
        super(UserChangeForm, self).__init__(*args, **kwargs)
        self.fields['name'].initial = self.instance.name

        self.fields['name'].validators = self._meta.model._meta.get_field('_name').validators

    def clean(self, *args, **kwargs):
        super(UserChangeForm, self).clean(*args, **kwargs)
        self.instance.name = self.cleaned_data.get('name')


Update django-admin (4)

@admin.register(User)
class UserAdmin(AuthUserAdmin):
    form = UserChangeForm

    fieldsets = [
        (None, {'fields': ['username', 'password']}),
        ('Personal Data', {'fields': [
            'name',
        ]}),
    ]

    list_display = ('username', 'name')


Checklist

☑️ Update the QuerySet

☑️ Exclude Pseudonyms

☑️ Update django-admin
